Computerized Laser and Contact Coordinate Measuring Machine

Equipment:

Nikon-Metris LK Integra Coordinate Measuring Machine

XC65D Tri-laser Cross Scanner Head

LC15Dx Laser Scanner Head

Renishaw TP200 Touch-trigger Probe

Renishaw SP25M Scanning Probe

Application:

Non-contact laser-based and contact-based computerized measurement of component features and dimensions from failed and failure-related components


Automated Optical and Contact Contour Measuring Machine

Equipment:

Micro-Vu Vertex Optical Based Contour Measuring Machine

Renishaw TP-20 Touch Trigger Probe

Application:

Non-contact optical contour measurement and contact probe-based measurement of failed and failure-related components


Laser Micrometer

Equipment:

Mitutoyo LSM-9506 Laser Micrometer

Application:

Non-contact optical measuring system capable of failed and failure related components. The laser micrometer performs measurements of objects ranging from 0.02″ (0.5mm) to 2.36″ (60mm).


HANDHELD 3D SCANNERS

EQUIPMENT:

Artec Eva

Artec Space Spider

APPLICATION:

High-resolution portable structured light scanners used to digitally capture small-to-medium sized objects for textured 3D modeling, reverse engineering, and forensic investigation


Long Range 3d Scanner

Equipment:

Surphaser 100HSX 3D Laser Scanner

Application:

Reverse engineering 3D laser scanner capable of sub-millimeter accuracy scans of aircraft, vehicles, accident scenes, component features and dimensions from failed and failure-related components.


Portable Coordinate Measuring Machine

Equipment:

Nikon MMDx100 Handheld Scanner

Application:

Portable laser-based scanner with contact-based computerized measurements of component features and dimensions from failed and failure-related components.


Surface Contour Measurement Capability

Equipment:

Mitutoyo Formtracer SV-C4500 Surface Roughness / Contour Measuring System

Application:

Measurement of failed and failure-related component surface contour, shape, form and roughness features
